Ventarch Door & Window Systems — 37 mm Sliding Window, presented by Inspire Windoors .

Brand and presenter

• Brand: Ventarch Door & Window Systems .

• Presented by: Inspire Windoors .

Track size

• 2‑Track: 90 mm .

• 3‑Track: 140 mm .

Sash size

• Handle: 83 mm .

• Top/Bottom: 83 mm .

• Intersection: 25 mm / 83 mm .

Frame capacity

• Maximum height: 3600 mm .

• Maximum width: 1200 mm (per panel indicated) .

Glass width

• Minimum: 6 mm .

• Maximum: 24 mm .

Glass options

• Toughened glass for impact resistance and safer break behavior in active zones .

• Security glass (laminated) for better intrusion resistance and acoustic comfort .

• DGU glass for thermal efficiency and condensation control in sun‑exposed or noisy locations .

• Security DGU glass combining laminated safety with insulated performance for premium openings and ground‑level spans .

Design and benefits

• Slim 37 mm profile enhances daylight and views while multi‑track flexibility supports wider clear openings and smooth gliding .

• System diagrams clarify section geometry for 2‑Track and 3‑Track with leg to aid accurate specification and fabrication .

Credentials

15+ years of experience | 180+ team members | 10,000+ projects—ensuring professional fabrication, installation, and after‑sales service for Ventarch systems.
