Candor View — PS 83 Mini Linea, presented by Inspire Windoors .

(0 reviews)

Brand and presenter

  • Brand: Candor View .

  • Presented by: Inspire Windoors .

System type

  • Sliding system offered in 2‑Track and 3‑Track configurations for flexible panel combinations and wide clear openings .

Track size

  • 2‑Track: 83 mm / 40 mm .

  • 3‑Track: 124 mm / 40 mm .

Sash dimensions

  • Handle: 47 mm / 92 mm .

  • Top/Bottom: 29 / 43 mm .

  • Intersection: 17.5 mm .

Frame capacity

  • Maximum height: 3048 mm .

  • Maximum width: 2000 mm (per panel indicated) .

Glass compatibility

  • Minimum glass thickness: 6 mm .

  • Maximum glass thickness: 24 mm .

Glass options

  • Toughened glass for higher impact resistance and safer break behavior in active areas .

  • Security glass (laminated) for elevated safety, intrusion resistance, and better acoustic control .

  • DGU glass for improved thermal insulation and energy efficiency in sun‑exposed or noise‑affected elevations .

  • Security DGU glass combining laminated safety with insulated performance for premium sliders and ground‑level openings .

Design and benefits

  • Slimmer profiles prioritize daylight and modern aesthetics while accommodating insect screens for comfort and practicality .

  • Multi‑track flexibility supports wider spans and smooth operation in living rooms, balconies, and premium façades .

Technical illustration

Profile drawings for 2‑Track and 3‑Track plus a close‑up section provide section geometry for accurate specification and fabrication detailing .

Credentials

15+ years of experience | 180+ team members | 10,000+ projects—demonstrating large‑scale delivery capability and dependable after‑sales service .Click For Enquiry

Description

Overview

PS 83 Mini Linea is a non‑insulated, minimalistic sliding system optimized for heights up to approximately 3 meters, designed to maximize natural light with slimmer profile widths and clean, contemporary lines . Available with double‑glass panels and compatible with insect screens, it suits large surface areas up to about 6 square meters per panel as indicated in the brochure text context .
